Description
| ITEM | DESCRIPTION | NRD-1600 | |||
| CAPACITY | Drilling capacity (mm) | Steel | 40 | Cast Iron | 50 |
| Tapping capacity (mm) | Steel | M25 | Cast Iron | M32 | |
| Boring Capacity (mm) | Steel | Cast Iron | |||
| Distance from column face to spindle center (mm) | Min | 300 | |||
| Max | 1000 | ||||
| Distance from column center to arm end (mm) | 1365 | ||||
| Distance from base plate to spindle end | Min | 280 | |||
| Max | 1100 | ||||
| SPINDLE | Taper | MT4 | |||
| Diameter of spindle/quill | Spindle | 65 | Quill | 80 | |
| Spindle stroke (mm) | 220 | ||||
| Number of spindle speeds (step) | 9 | ||||
| Spindle Speed | 50 Hz | 40, 62, 96, 145, 225, 345, 530, 820, 1270 | |||
| 60 Hz | 48, 75, 115, 175, 270, 415, 635, 985, 1525 | ||||
| Number of spindle feeds (step) | 3 | ||||
| Feeds er revolution (mm/rev) | 0.11, 0.22, 0.33 | ||||
| SPINDLE HEAD | Horizontal travel (mm) | 700 | |||
| Max. height floor to top of head (mm) | 2370 | ||||
| COLUMN ARM | Column sleeve diameter (mm) | Ø 240 | |||
| Vertical travel of arm (mm) | 600 | ||||
| WORK TABLE | Size of working surface | 530X410 | |||
| BASE PLATE | Size of working surface | 1000X700 | |||
| MOTOR | Main motor (kW) | 2.2 | |||
| Arm vertical moving motor (kW) | 0.75 | ||||
| Clamping motor (kW) | |||||
| Coolant pump motor Wvl | 100 | ||||
| Power ejecting pack (Wl | |||||
| MACHINE DIMENSION | Height of floor to column cap (mm) | 1980 | |||
| Base size (mm) | 1600X700X160 | ||||
| Machine mass (kg) | 1700 | ||||
